Pentax Super-Takumar 105mm f/2.8

We don’t have a vetted photo of this one yet. Own a copy? Send us a packshot and we’ll credit you.

A five-element short tele that is small for its focal length and keeps the 49mm filter thread. Contrast is modest and highlights bloom a little wide open; stopped to f/4 it is properly sharp. The multi-coated successor is a touch heavier at about 300g with the same 1.2m close focus, which is the main limitation for tight inserts.

Key specs

Focal length

105 mm

Max aperture

f/2.8

Mount

M42 screw

Image circle

Full frame

Close focus

1.2 m

Filter thread

49 mm

Weight

290 g

Field of view by sensor

Full frame

19.5° horizontal · frames like 105 mm on full frame

Super 35

13.5° horizontal · frames like 151.8 mm on full frame

Micro Four Thirds

9.4° horizontal · frames like 218.5 mm on full frame

What it goes on

M42's 45.46mm flange means a cheap glassless ring puts it on EF and every mirrorless mount. A/M switch to M. Light enough to hang off an adapter without lens support, and the long smooth focus throw suits follow-focus gears.

• Canon EF camerasWith adapterALEXA 265, ALEXA 35, ALEXA Mini LF, Pocket Cinema Camera 6K G2 +14 more

  M42-EOS flanged ring. Cheap and common. Pick a flanged ring that presses the auto-aperture pin. On full-frame EF DSLRs a few lenses (Helios 44-2, some Takumars) can catch the mirror at infinity.

• Sony E camerasWith adapterRonin 4D-6K, Ronin 4D-8K, Alpha 1 II, Alpha 7 IV +13 more

  Novoflex · K&F Concept · Fotodiox. 27.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• Canon RF camerasWith adapterEOS C400, EOS C50, EOS C70, EOS C80 +10 more

  Novoflex · K&F Concept · Fotodiox. 25.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• L-Mount camerasWith adapterCinema Camera 6K, PYXIS 12K, PYXIS 6K, Ronin 4D-6K +6 more

  Novoflex · K&F Concept · Fotodiox. 25.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• Micro Four Thirds camerasWith adapterMicro Studio Camera 4K G2, Pocket Cinema Camera 4K, Lumix BGH1, Lumix GH6 +1 more

  Novoflex · K&F Concept · Fotodiox. 26.2 mm of room — a plain mechanical adapter. Manual focus and iris.

• Nikon Z camerasWith adapterKOMODO-X 6K S35, V-RAPTOR [X] 8K VV, V-RAPTOR XE

  Novoflex · K&F Concept · Fotodiox. 29.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• Leica M camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, Ronin 4D-6K +1 more

  17.7 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

• LPL camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, URSA Cine 17K 65

  1.5 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

See every camera this lens fits →

Sources: allphotolenses.com, allphotolenses.com
