Pentax Super-Multi-Coated Takumar 24mm f/3.5

We don’t have a vetted photo of this one yet. Own a copy? Send us a packshot and we’ll credit you.

Nine-element retrofocus wide and the widest Takumar most video shooters actually carry. Centre sharpness is good from wide open while the corners stay soft and vignetted until f/8, which reads as period character rather than a flaw on moving images. The 58mm front breaks the 49mm filter standard of the rest of the set, so a matched kit needs step-up rings. Close focus of 25cm makes it useful for wide inserts.

Key specs

Focal length

24 mm

Max aperture

f/3.5

Mount

M42 screw

Image circle

Full frame

Close focus

0.25 m

Filter thread

58 mm

Weight

247 g

Field of view by sensor

Full frame

73.7° horizontal · frames like 24 mm on full frame

Super 35

54.8° horizontal · frames like 34.7 mm on full frame

Micro Four Thirds

39.6° horizontal · frames like 49.9 mm on full frame

What it goes on

M42's 45.46mm flange means a cheap glassless ring puts it on EF and every mirrorless mount. Flip the A/M switch to M (or use an adapter with an inner flange that presses the pin) so the iris follows the ring. Popular on Super 35 and speed-boosted MFT as a roughly 35mm-equivalent.

• Canon EF camerasWith adapterALEXA 265, ALEXA 35, ALEXA Mini LF, Pocket Cinema Camera 6K G2 +14 more

  M42-EOS flanged ring. Cheap and common. Pick a flanged ring that presses the auto-aperture pin. On full-frame EF DSLRs a few lenses (Helios 44-2, some Takumars) can catch the mirror at infinity.

• Sony E camerasWith adapterRonin 4D-6K, Ronin 4D-8K, Alpha 1 II, Alpha 7 IV +13 more

  Novoflex · K&F Concept · Fotodiox. 27.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• Canon RF camerasWith adapterEOS C400, EOS C50, EOS C70, EOS C80 +10 more

  Novoflex · K&F Concept · Fotodiox. 25.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• L-Mount camerasWith adapterCinema Camera 6K, PYXIS 12K, PYXIS 6K, Ronin 4D-6K +6 more

  Novoflex · K&F Concept · Fotodiox. 25.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• Micro Four Thirds camerasWith adapterMicro Studio Camera 4K G2, Pocket Cinema Camera 4K, Lumix BGH1, Lumix GH6 +1 more

  Novoflex · K&F Concept · Fotodiox. 26.2 mm of room — a plain mechanical adapter. Manual focus and iris.

• Nikon Z camerasWith adapterKOMODO-X 6K S35, V-RAPTOR [X] 8K VV, V-RAPTOR XE

  Novoflex · K&F Concept · Fotodiox. 29.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• Leica M camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, Ronin 4D-6K +1 more

  17.7 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

• LPL camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, URSA Cine 17K 65

  1.5 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

See every camera this lens fits →

Sources: allphotolenses.com, allphotolenses.com
