KMZ Jupiter-37A 135mm f/3.5

We don’t have a vetted photo of this one yet. Own a copy? Send us a packshot and we’ll credit you.

A 4-element/3-group recalculation of the Zeiss Sonnar 135/3.5, light for a 135 and sharp from wide open. The 12-blade preset iris keeps out-of-focus highlights circular at all stops. The 'A' suffix means the Soviet interchangeable-tail system: the rear mount unscrews and can be swapped (M42 tail is the usual one); MC versions appeared around 1980 and the later Jupiter-37AM is a lighter revision. Sources disagree on production years, so none is given.

Key specs

Focal length

135 mm

Max aperture

f/3.5

Mount

M42 screw

Image circle

Full frame

Close focus

1.2 m

Filter thread

52 mm

Weight

410 g

Field of view by sensor

Full frame

15.2° horizontal · frames like 135 mm on full frame

Super 35

10.5° horizontal · frames like 195.2 mm on full frame

Micro Four Thirds

7.3° horizontal · frames like 280.9 mm on full frame

What it goes on

Supplied with an M42 'A' tail, so a glassless M42 adapter to EF or mirrorless works; check the tail's set screws are tight, as a loose tail causes rotation and infinity errors. The stepless preset aperture suits video, and the lens is a common candidate for oval-aperture anamorphic-look mods. IronGlass sells cine-modded copies.

• Canon EF camerasWith adapterALEXA 265, ALEXA 35, ALEXA Mini LF, Pocket Cinema Camera 6K G2 +14 more

  M42-EOS flanged ring. Cheap and common. Pick a flanged ring that presses the auto-aperture pin. On full-frame EF DSLRs a few lenses (Helios 44-2, some Takumars) can catch the mirror at infinity.

• Sony E camerasWith adapterRonin 4D-6K, Ronin 4D-8K, Alpha 1 II, Alpha 7 IV +13 more

  Novoflex · K&F Concept · Fotodiox. 27.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• Canon RF camerasWith adapterEOS C400, EOS C50, EOS C70, EOS C80 +10 more

  Novoflex · K&F Concept · Fotodiox. 25.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• L-Mount camerasWith adapterCinema Camera 6K, PYXIS 12K, PYXIS 6K, Ronin 4D-6K +6 more

  Novoflex · K&F Concept · Fotodiox. 25.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• Micro Four Thirds camerasWith adapterMicro Studio Camera 4K G2, Pocket Cinema Camera 4K, Lumix BGH1, Lumix GH6 +1 more

  Novoflex · K&F Concept · Fotodiox. 26.2 mm of room — a plain mechanical adapter. Manual focus and iris.

• Nikon Z camerasWith adapterKOMODO-X 6K S35, V-RAPTOR [X] 8K VV, V-RAPTOR XE

  Novoflex · K&F Concept · Fotodiox. 29.5 mm of room — a plain mechanical adapter. Manual focus and iris.

• Leica M camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, Ronin 4D-6K +1 more

  17.7 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

• LPL camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, URSA Cine 17K 65

  1.5 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

See every camera this lens fits →

Sources: allphotolenses.com, pentaxforums.com, ironglassadapters.com
