Canon New FD 24mm f/2.8

We don’t have a vetted photo of this one yet. Own a copy? Send us a packshot and we’ll credit you.

The New FD version gained an element over the 1971/1973 lenses (10 elements in 9 groups) and dropped to a 52 mm thread. Light, cheap and common, so it is the default wide in budget FD kits. Matches the colour of the other New FD primes well.

Key specs

Focal length

24 mm

Max aperture

f/2.8

Mount

Canon FD

Image circle

Full frame

Close focus

0.3 m

Filter thread

52 mm

Weight

240 g

Field of view by sensor

Full frame

73.7° horizontal · frames like 24 mm on full frame

Super 35

54.8° horizontal · frames like 34.7 mm on full frame

Micro Four Thirds

39.6° horizontal · frames like 49.9 mm on full frame

What it goes on

FD sits at a 42 mm flange, 2 mm shorter than EF, so a plain EF adapter loses infinity unless it carries a corrective glass element; the clean fix is a permanent mount swap (EdMika kits, also sold through Simmod). On Sony E, L, RF, Z, X and MFT bodies a simple tube adapter with an aperture-release ring works with no glass.

• Sony E camerasWith adapterRonin 4D-6K, Ronin 4D-8K, Alpha 1 II, Alpha 7 IV +13 more

  Novoflex · K&F Concept · Fotodiox. 24 mm of room — a plain mechanical adapter. Manual focus and iris.

• Canon RF camerasWith adapterEOS C400, EOS C50, EOS C70, EOS C80 +10 more

  Novoflex · K&F Concept · Fotodiox. 22 mm of room — a plain mechanical adapter. Manual focus and iris.

• L-Mount camerasWith adapterCinema Camera 6K, PYXIS 12K, PYXIS 6K, Ronin 4D-6K +6 more

  Novoflex · K&F Concept · Fotodiox. 22 mm of room — a plain mechanical adapter. Manual focus and iris.

• Micro Four Thirds camerasWith adapterMicro Studio Camera 4K G2, Pocket Cinema Camera 4K, Lumix BGH1, Lumix GH6 +1 more

  Novoflex · K&F Concept · Fotodiox. 22.8 mm of room — a plain mechanical adapter. Manual focus and iris.

• Nikon Z camerasWith adapterKOMODO-X 6K S35, V-RAPTOR [X] 8K VV, V-RAPTOR XE

  Novoflex · K&F Concept · Fotodiox. 26 mm of room — a plain mechanical adapter. Manual focus and iris.

• Leica M camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, Ronin 4D-6K +1 more

  14.2 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

• Canon EF camerasOptical adapterALEXA 265, ALEXA 35, ALEXA Mini LF, Pocket Cinema Camera 6K G2 +14 more

  EdMika FD-EF conversion kit (no glass). FD sits 2 mm closer than EF, so a plain adapter loses infinity and glass adapters soften the image. The accepted fix is replacing the mount (EdMika) — or using a mirrorless body, where FD adapts trivially.

See every camera this lens fits →

Sources: en.wikipedia.org, fdtoef.com
