Canon K35 24mm T1.6

We don’t have a vetted photo of this one yet. Own a copy? Send us a packshot and we’ll credit you.

Covers full frame, which is a large part of why the set became so sought after for large-format digital. Aspherical design with strong veiling flare and low contrast wide open that tightens up by T2.8. Canon's 1970s answer to the Zeiss Super Speeds, recognised with an Academy Scientific and Technical award in 1977; the rehoused iris gives rounder bokeh than the originals. Specs are for the TLS rehousing.

Key specs

Focal length

24 mm

Max aperture

T1.6

Mount

Mitchell BNCR, ARRI Bayonet, PL

Image circle

Full frame

Close focus

0.3 m

Front diameter

110 mm

Weight

1.27 kg

Field of view by sensor

Full frame

73.7° horizontal · frames like 24 mm on full frame

Super 35

54.8° horizontal · frames like 34.7 mm on full frame

Micro Four Thirds

39.6° horizontal · frames like 49.9 mm on full frame

What it goes on

Most working sets are TLS rehousings in PL (110mm fronts, cam focus); GL Optics and P+S Technik have housed them too. Original barrels came in BNCR and Arri bayonet and were commonly PL-converted; being cine mounts they do not adapt usefully to stills bodies other than via PL adapters.

• PL camerasNativeALEXA 265, ALEXA 35, PYXIS 12K, PYXIS 6K +15 more
• Sony E camerasWith adapterRonin 4D-6K, Ronin 4D-8K, Alpha 1 II, Alpha 7 IV +13 more

  Wooden Camera E to PL · Vocas PL to E · Metabones PL-E. Solid and common. Support the lens — the E-mount is not built to carry a heavy cine zoom on its own.

• Canon RF camerasWith adapterEOS C400, EOS C50, EOS C70, EOS C80 +10 more

  Wooden Camera RF to PL · Canon PL-RF (C400 / C80) · Kipon PL-RF. Common; use lens support with heavy glass.

• L-Mount camerasWith adapterCinema Camera 6K, PYXIS 12K, PYXIS 6K, Ronin 4D-6K +6 more

  Leitz L-PL · Wooden Camera L to PL · Sigma MC-31. Common; use lens support with heavy glass.

• Micro Four Thirds camerasWith adapterMicro Studio Camera 4K G2, Pocket Cinema Camera 4K, Lumix BGH1, Lumix GH6 +1 more

  Wooden Camera MFT to PL · MTF PL to MFT. Works, with a 2x crop on Super 35 glass relative to full frame.

• LPL camerasWith adapterALEXA 265, ALEXA 35, ALEXA Mini LF, URSA Cine 17K 65

  ARRI PL-to-LPL Adapter. ARRI's own adapter, passes LDS / Cooke /i lens data.

• Nikon Z camerasWith adapterKOMODO-X 6K S35, V-RAPTOR [X] 8K VV, V-RAPTOR XE

  Wooden Camera Z to PL · Kipon PL-NIK Z. Common; use lens support with heavy glass.

• Canon EF camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, Pocket Cinema Camera 6K G2 +14 more

  17.5 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

• Leica M camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, Ronin 4D-6K +1 more

  33.7 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

• B4 (2/3") camerasWith adapter· by flange mathsURSA Broadcast G2, URSA Mini Pro 4.6K G2, AJ-CX4000

  13.5 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

• Nikon F camerasWith adapter· by flange mathsURSA Mini Pro 12K, URSA Mini Pro 12K OLPF, URSA Mini Pro 4.6K G2

  15 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

See every camera this lens fits →

Sources: sharegrid.com, emmyland.com, newprovideo.com
