Canon New FD 200mm f/2.8 (internal focus)

We don’t have a vetted photo of this one yet. Own a copy? Send us a packshot and we’ll credit you.

Second New FD version with seven elements in six groups and rear/internal focusing, so the barrel does not extend and focus is light. The 1979 first version is a five-element unit-focus lens that only reaches 1.8 m. No low-dispersion glass, so expect purple/green fringing on backlit edges wide open.

Key specs

Focal length

200 mm

Max aperture

f/2.8

Mount

Canon FD

Image circle

Full frame

Close focus

1.5 m

Filter thread

72 mm

Weight

735 g

Field of view by sensor

Full frame

10.3° horizontal · frames like 200 mm on full frame

Super 35

7.1° horizontal · frames like 289.2 mm on full frame

Micro Four Thirds

5° horizontal · frames like 416.2 mm on full frame

What it goes on

FD sits at a 42 mm flange, 2 mm shorter than EF, so a plain EF adapter loses infinity unless it carries a corrective glass element; the clean fix is a permanent mount swap (EdMika kits, also sold through Simmod). On Sony E, L, RF, Z, X and MFT bodies a simple tube adapter with an aperture-release ring works with no glass. Support the lens rather than the adapter on small mirrorless mounts.

• Sony E camerasWith adapterRonin 4D-6K, Ronin 4D-8K, Alpha 1 II, Alpha 7 IV +13 more

  Novoflex · K&F Concept · Fotodiox. 24 mm of room — a plain mechanical adapter. Manual focus and iris.

• Canon RF camerasWith adapterEOS C400, EOS C50, EOS C70, EOS C80 +10 more

  Novoflex · K&F Concept · Fotodiox. 22 mm of room — a plain mechanical adapter. Manual focus and iris.

• L-Mount camerasWith adapterCinema Camera 6K, PYXIS 12K, PYXIS 6K, Ronin 4D-6K +6 more

  Novoflex · K&F Concept · Fotodiox. 22 mm of room — a plain mechanical adapter. Manual focus and iris.

• Micro Four Thirds camerasWith adapterMicro Studio Camera 4K G2, Pocket Cinema Camera 4K, Lumix BGH1, Lumix GH6 +1 more

  Novoflex · K&F Concept · Fotodiox. 22.8 mm of room — a plain mechanical adapter. Manual focus and iris.

• Nikon Z camerasWith adapterKOMODO-X 6K S35, V-RAPTOR [X] 8K VV, V-RAPTOR XE

  Novoflex · K&F Concept · Fotodiox. 26 mm of room — a plain mechanical adapter. Manual focus and iris.

• Leica M camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, Ronin 4D-6K +1 more

  14.2 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

• Canon EF camerasOptical adapterALEXA 265, ALEXA 35, ALEXA Mini LF, Pocket Cinema Camera 6K G2 +14 more

  EdMika FD-EF conversion kit (no glass). FD sits 2 mm closer than EF, so a plain adapter loses infinity and glass adapters soften the image. The accepted fix is replacing the mount (EdMika) — or using a mirrorless body, where FD adapts trivially.

See every camera this lens fits →

Sources: en.wikipedia.org, fdtoef.com
