Kinoptik Apochromat 18mm T2.8

We don’t have a vetted photo of this one yet. Own a copy? Send us a packshot and we’ll credit you.

A very compact wide with strong falloff toward the edges. French cine lenses built mainly for Cameflex cameras; the Apochromats use a six-element, four-group double-Gauss layout that keeps the set consistent. Good central sharpness with strong flare and visible light falloff toward the edges. Specs are for the P+S Technik rehousing (104mm front), which the rental house rates as covering Super 35.

Key specs

Focal length

18 mm

Max aperture

T2.8

Mount

ARRI Standard, PL

Image circle

Super 35

Close focus

0.2 m

Front diameter

104 mm

Weight

680 g

Field of view by sensor

Full frame

90° horizontal · frames like 18 mm on full frame

Super 35

69.3° horizontal · frames like 26 mm on full frame

Micro Four Thirds

51.3° horizontal · frames like 37.5 mm on full frame

What it goes on

Originals are mostly in Cameflex mount (also Arri Standard and C-mount), all of which adapt to mirrorless cameras. For production use they are rehoused in PL by P+S Technik, Whitepoint Optics, GL Optics or Zero Optik, with LPL and EF options from some houses.

• PL camerasNativeALEXA 265, ALEXA 35, PYXIS 12K, PYXIS 6K +15 more
• Sony E camerasWith adapterRonin 4D-6K, Ronin 4D-8K, Alpha 1 II, Alpha 7 IV +13 more

  Wooden Camera E to PL · Vocas PL to E · Metabones PL-E. Solid and common. Support the lens — the E-mount is not built to carry a heavy cine zoom on its own.

• Canon RF camerasWith adapterEOS C400, EOS C50, EOS C70, EOS C80 +10 more

  Wooden Camera RF to PL · Canon PL-RF (C400 / C80) · Kipon PL-RF. Common; use lens support with heavy glass.

• L-Mount camerasWith adapterCinema Camera 6K, PYXIS 12K, PYXIS 6K, Ronin 4D-6K +6 more

  Leitz L-PL · Wooden Camera L to PL · Sigma MC-31. Common; use lens support with heavy glass.

• Micro Four Thirds camerasWith adapterMicro Studio Camera 4K G2, Pocket Cinema Camera 4K, Lumix BGH1, Lumix GH6 +1 more

  Wooden Camera MFT to PL · MTF PL to MFT. Works, with a 2x crop on Super 35 glass relative to full frame.

• LPL camerasWith adapterALEXA 265, ALEXA 35, ALEXA Mini LF, URSA Cine 17K 65

  ARRI PL-to-LPL Adapter. ARRI's own adapter, passes LDS / Cooke /i lens data.

• Nikon Z camerasWith adapterKOMODO-X 6K S35, V-RAPTOR [X] 8K VV, V-RAPTOR XE

  Wooden Camera Z to PL · Kipon PL-NIK Z. Common; use lens support with heavy glass.

• Canon EF camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, Pocket Cinema Camera 6K G2 +14 more

  8 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

• Leica M camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, Ronin 4D-6K +1 more

  24.2 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

• B4 (2/3") camerasWith adapter· by flange mathsURSA Broadcast G2, URSA Mini Pro 4.6K G2, AJ-CX4000

  4 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

• Nikon F camerasWith adapter· by flange mathsURSA Mini Pro 12K, URSA Mini Pro 12K OLPF, URSA Mini Pro 4.6K G2

  5.5 mm of room for a plain ring. Check rear-element and mirror clearance before buying.

See every camera this lens fits →

Sources: camtec.tv, vantagefilm.com, whitepointoptics.com
