Angénieux Optimo 24-290mm

Compare with Optimo Style 25-250mm

Key specs

Focal length: 24–290 mm
Max aperture: T2.8
Mount: PL, Canon EF
Image circle: Super 35
Front diameter: 162 mm
Weight: 11 kg

From the manufacturer

Focal length: 24-290 mm (12x)
Max aperture: T2.8
Mount: PL (interchangeable to PV / Canon EF)
Format coverage: S35 3-perf (30 mm diagonal)
Front diameter: 162 mm
Weight: 11 kg

Source: angenieux.com. Spotted a mistake? Tell us.

Field of view by sensor

Full frame: 73.7° – 7.1° horizontal · frames like 24 mm – 290 mm on full frame
Super 35: 54.8° – 4.9° horizontal · frames like 34.7 mm – 419.3 mm on full frame
Micro Four Thirds: 39.6° – 3.4° horizontal · frames like 49.9 mm – 603.5 mm on full frame

What it goes on

PL camerasNativeALEXA 265, ALEXA 35, PYXIS 12K, PYXIS 6K +15 more
Canon EF camerasNativeALEXA 265, ALEXA 35, ALEXA Mini LF, Pocket Cinema Camera 6K G2 +14 more
Sony E camerasElectronic adapterRonin 4D-6K, Ronin 4D-8K, Alpha 1 II, Alpha 7 IV +13 more
Metabones EF-E Smart Adapter · Sigma MC-11. Iris control and IS work; autofocus works on most lenses but is slower than native, and continuous video AF is hit-and-miss.
Canon RF camerasElectronic adapterEOS C400, EOS C50, EOS C70, EOS C80 +10 more
Canon Mount Adapter EF-EOS R · Canon Drop-In Filter Adapter (VND). Canon's own adapter: EF lenses behave natively, and the drop-in version adds a variable ND behind the lens.
L-Mount camerasElectronic adapterCinema Camera 6K, PYXIS 12K, PYXIS 6K, Ronin 4D-6K +6 more
Sigma MC-21. Iris and single-shot AF work; no continuous AF in video.
Micro Four Thirds camerasElectronic adapterMicro Studio Camera 4K G2, Pocket Cinema Camera 4K, Lumix BGH1, Lumix GH6 +1 more
Metabones EF-MFT Smart Adapter · Viltrox EF-M1. Iris control works; AF is slow. Remember the 2x crop — or use a Speed Booster.
LPL camerasWith adapterALEXA 265, ALEXA 35, ALEXA Mini LF, URSA Cine 17K 65
ARRI PL-to-LPL Adapter. ARRI's own adapter, passes LDS / Cooke /i lens data.
Nikon Z camerasElectronic adapterKOMODO-X 6K S35, V-RAPTOR [X] 8K VV, V-RAPTOR XE
Fringer EF-NZ · Techart TZC-01. Third-party electronic adapters — iris and AF work with most lenses, firmware dependent.
Leica M camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, Ronin 4D-6K +1 more
24.2 mm of room for a plain ring. Check rear-element and mirror clearance before buying.
B4 (2/3") camerasWith adapter· by flange mathsURSA Broadcast G2, URSA Mini Pro 4.6K G2, AJ-CX4000
4 mm of room for a plain ring. Check rear-element and mirror clearance before buying.
Nikon F camerasWith adapter· by flange mathsURSA Mini Pro 12K, URSA Mini Pro 12K OLPF, URSA Mini Pro 4.6K G2
5.5 mm of room for a plain ring. Check rear-element and mirror clearance before buying.
