Angénieux Optimo Ultra 12x

Compare with EF 100-400mm f/4.5-5.6L IS II USM

Key specs

Focal length: 36–435 mm
Max aperture: T4.2
Mount: PL
Image circle: Large format / VV
Front diameter: 162 mm
Weight: 12.6 kg

From the manufacturer

Focal length: 36-435 mm FF/VV, 26-320 mm U35, 24-290 mm S35
Max aperture: T4.2 (FF/VV), T3.1 (U35), T2.8 (S35)
Mount: PL (LPL compatible)
Format coverage: FF/VV (46.3 mm), U35 (34.6 mm), S35 (31.1 mm) via IRO kits
Front diameter: 162 mm
Weight: 12.6-12.75 kg

Source: angenieux.com. Spotted a mistake? Tell us.

Field of view by sensor

Full frame: 53.1° – 4.7° horizontal · frames like 36 mm – 435 mm on full frame
Super 35: 38.2° – 3.3° horizontal · frames like 52 mm – 628.9 mm on full frame
Micro Four Thirds: 27° – 2.3° horizontal · frames like 74.9 mm – 905.2 mm on full frame

What it goes on

PL camerasNativeALEXA 265, ALEXA 35, PYXIS 12K, PYXIS 6K +15 more
Sony E camerasWith adapterRonin 4D-6K, Ronin 4D-8K, Alpha 1 II, Alpha 7 IV +13 more
Wooden Camera E to PL · Vocas PL to E · Metabones PL-E. Solid and common. Support the lens — the E-mount is not built to carry a heavy cine zoom on its own.
Canon RF camerasWith adapterEOS C400, EOS C50, EOS C70, EOS C80 +10 more
Wooden Camera RF to PL · Canon PL-RF (C400 / C80) · Kipon PL-RF. Common; use lens support with heavy glass.
L-Mount camerasWith adapterCinema Camera 6K, PYXIS 12K, PYXIS 6K, Ronin 4D-6K +6 more
Leitz L-PL · Wooden Camera L to PL · Sigma MC-31. Common; use lens support with heavy glass.
Micro Four Thirds camerasWith adapterMicro Studio Camera 4K G2, Pocket Cinema Camera 4K, Lumix BGH1, Lumix GH6 +1 more
Wooden Camera MFT to PL · MTF PL to MFT. Works, with a 2x crop on Super 35 glass relative to full frame.
LPL camerasWith adapterALEXA 265, ALEXA 35, ALEXA Mini LF, URSA Cine 17K 65
ARRI PL-to-LPL Adapter. ARRI's own adapter, passes LDS / Cooke /i lens data.
Nikon Z camerasWith adapterKOMODO-X 6K S35, V-RAPTOR [X] 8K VV, V-RAPTOR XE
Wooden Camera Z to PL · Kipon PL-NIK Z. Common; use lens support with heavy glass.
Leica M camerasWith adapter· by flange mathsALEXA 265, ALEXA 35, ALEXA Mini LF, Ronin 4D-6K +1 more
24.2 mm of room for a plain ring. Check rear-element and mirror clearance before buying.
B4 (2/3") camerasWith adapter· by flange mathsURSA Broadcast G2, URSA Mini Pro 4.6K G2, AJ-CX4000
4 mm of room for a plain ring. Check rear-element and mirror clearance before buying.
Nikon F camerasWith adapter· by flange mathsURSA Mini Pro 12K, URSA Mini Pro 12K OLPF, URSA Mini Pro 4.6K G2
5.5 mm of room for a plain ring. Check rear-element and mirror clearance before buying.
